There are 10 processors in the Embedded 9004 Series, made using a 5nm chip process, with 16 to 96 cores see table) and dissipating from 200 to 400W.
Security features and reliability are suited to applications with enterprise-class needs, according to the company.
“Embedded 9004 Series processors are targeted for heavy workload, always-on embedded systems requiring compute performance and I/O agility in a power-optimised profile,” said AMD embedded solutions general manager Rajneesh Gaur. “With the launch of Embedded 9004 Series processors, we’re bringing data centre-level computing to embedded networking, security, storage and industrial applications.”
Features include:
- Non-transparent bridging enabling data exchange between two redundant CPUs
- Support for non-volatile DIMM memory (NVDIMM) to assist data retention through power failure
- Dual SPI supports two off-chip ROMs for secure boot.
- Up to seven-year planned availability
| Model | Cores | Nominal power (W) |
Power (W) |
Base freq (GHz) |
Max (GHz) |
|
| 100-000000921 | 9654 | 96 | 360 | 320-400 | 2.4 | 3.7 |
| 100-000000912 | 9554 | 64 | 360 | 320-400 | 3.1 | 3.75 |
| 100-000000913 | 9454 | 48 | 290 | 240-300 | 2.75 | 3.8 |
| 100-000000914 | 9354 | 32 | 280 | 240-300 | 3.25 | 3.8 |
| 100-000000915 | 9254 | 24 | 200 | 200-240 | 2.9 | 4.15 |
| 100-000000916 | 9124 | 16 | 200 | 200-240 | 3.0 | 3.7 |
| 100-000000917 | 9654P | 96 | 360 | 320-400 | 2.4 | 3.7 |
| 100-000000918 | 9554P | 64 | 360 | 320-400 | 3.1 | 3.75 |
| 100-000000919 | 9454P | 48 | 290 | 240-300 | 2.75 | 3.8 |
| 100-000000920 | 9354P | 32 | 280 | 240-300 | 3.25 | 3.8 |
Evaluation kits are available to ‘qualified customers’, said AMD, with a reference board, documentation and development tool kits.
The processors are sampling now and production shipments are scheduled for April 2023.
See AMD at Embedded World 2023, hall 2, stand 411.
